DesignMaster: Roofing CAD Library
Find the CAD detail you need
Our extensive roof detail CAD library allows you to match our market-leading products to your specification to see how they will perform in practice, ensuring that you select the ideal BMI Redland system for your project.
Jump to section
Roof Drawings available from BMI Redland
Roof Drawings available from BMI Redland
Roof drawings from our comprehensive roofing detail CAD library are available in both .dwg and .dxf formats to ensure easy integration into your working drawings. More than this, however, every detail in DesignMaster is accompanied by a complementary NBS-based specification clause, so whether you’re looking for pitched roof detail in .dwg format or even a specific pitched roof section detail, we can provide the relevant details to support your project.
Your unique project
Your unique project
At BMI Redland, we understand that every roofing project is unique. Our CAD drawings cover an extensive list of popular roof pitches, design features and even include additions, such as ornamental and ventilation tiles, to cover the full spectrum of roof system requirements. Please note that although we offer a wide range of product drawings to suit the needs of your project, ventilation product drawings can only be downloaded with a pitch of 35 degrees.
Get started
Get started
Access our free roofing CAD details today by using the selector below or contact our BMI Redland Technical Services team if you need a detail not listed in the library or for further support.
T: 0330 123 4585
E: technical.redland@bmigroup.com
